Light Weight LED Digital Display Screens Picture Wrinkle Less For Event Stage

Light Weight LED Digital Display Screens Picture Wrinkle Less For Event Stage

  • Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage
  • Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage
  • Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage
  • Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage
Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC, CE, ROHS
Model Number: PR - P5.95
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: flight case; export wooden case
Delivery Time: 15~25 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000Sqm/month
Contact Now
Detailed Product Description
Product: LED Digital Display Screens LED Brand: NATIONSTAR
Module Size: 250mm * 250mm Weight: 25Kg/SQM
Cabinet Size: 500mm * 500mm , 500mm * 1000mm Life Span: 100000H
Brightness: 1500CD/sqm Refresh Rate: 3840Hz
High Light:

event screen hire

,

large outdoor screen hire

Light Weight LED Digital Display Screens Picture Wrinkle Less For Event Stage





Application of LED Digital Display Screens

Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on .



Features of LED Digital Display Screens:

1. Light weight: The aluminum die-casting technology we adopt is about 7.5kg which is convenient for assembly and disassembly
2. Hight refresh rate: Over 2000 Hz refresh rate to ensure the picture wrinkle-less,line-less and stable
3. Low brightness and High gray scale:14Bit-16Bit gray scale to bring excellent performance when brightness is reduced to 25%.
4. Easy to install: Don't need to worry about the installation, it is easy, because of the design of the Die casting cabinet, Just like building block
5. High IP: The IP65 insures the reliable operation in different enrionment, and it is more safe
6. Low brightness and Hight gray scale:14Bit-16Bit gray scale to bring perfect display performance with no shadows

Advantages of LED Digital Display Screens:

1. We are led screen manufacturer for 11 years, we have rich experience in outdoor and indoor led display, quality is guaranteed

2. Up to 60% customer referral rate
3. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level
4. Our sales is peofessional and will give you Detailed answers for your concerns, and we have a strong technical team for your special needs,such as OEM and ODM service
5. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make different solutions accroding different requirements of customers





Detail Specifications of LED Digital Display Screens:



Parameter Value
Physical Parameter Pixel Configuration 1R1G1B
Pixel Pitch (mm) 5.95
Pixel Matrix per m2 (dots) 28224
Pixel Matrix per Module 42*42
Pixel Matrix per Panel 84*84 / 84*168
Module Dimensions (L*W) / (mm) 250*250
Module Quality per Cabinet 2*2 / 2*4
Panel Dimension (L*W*H) / (mm) 500*500*78 / 500*1000*78
Panel Material Die-Casting Aluminum
Panel Weight (Kg) 7
Electronic Parameter Color Grayscale (Bit) 16
Gray Scale per Color (Level) 65536
Refresh Rate (Hz) 1920
Driving Type 1/7
Frame Frequency (Hz) 50/60
Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
Optical Parameter Brightness (cd/m2) ≥1200
Color Temperature (K) 6500-7500
Color Contrast 4000:1
Optimal Horizontal Viewing Angle (°) 160
Optimal Vertical Viewing Angle 160
Electrical Parameter AC Input Voltage (V) 100~240
AC Input Frequency (Hz) 50/60
AC Input Power Maximum Value (W/m2) 800
AC Input Power Typical Value (W/m2) 300
Circumstance Parameter Storage Temperature (℃) -40~+60
Operating Temperature (℃) -20~+50
Storage Humidity (RH) 10%~90%
Operating Humidity (RH) 10%~90%
IP Rating (Front / Rear) IP63 / IP54
Lifrtime Typical Value (Hrs) 100,000
Installation type Cabinet Installation Type Rental
Maximum Number of Panel for Lifting 12 / 6



Light Weight LED Digital Display Screens Picture Wrinkle Less  For Event Stage 0





Our services:



1. Your inquiry about our products or the price will be replied within 8 hours.

2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.

3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.

4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
