Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size

Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size

  • Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size
  • Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size
  • Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size
  • Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size
Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC , CE , RHos
Model Number: PH10mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight case or Fumigation-Free Wooden Case
Delivery Time: 15~20 Working days
Payment Terms: L, T/T, Western Union, MoneyGram
Supply Ability: 2000SQM/Month
Contact Now
Detailed Product Description
Model: PH16mm LED Chip: Epistar/Cree/Nichia
Usage: OUTDOOR Display Function: Video
Tube Chip Color: Full Color Module Size(mm): 256x256
High Light:

outdoor led advertising signs

,

full color programmable led signs

Programmable Outdoor Full Color Led Signs, Full Colr Video Portable Outdoor Led Signs



P8/P10/P12/p16 outdoor led screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.

It characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.

It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.















Specifications:

Outdoor Fixed Installed Giant Advertising Media LED Displays
Main Pitch/mm P8 P10 P16

Module size/mm 256x128 160x160 256x256
Density of pixel/(dots/m2) 15,625 10,000 3,906
Pixel composition 1R1G1B 1R1G1B 1R1G1B
Led encapsulation SMD3535 DIP346 DIP346
Resolution of module 32x16 16X16 16X16
Optimum viewing distance ≥6 ≥10 ≥15
View angle / ° 140H,120V 110 H,60 V 110 H,60 V
Average power consumption/W/M2 500 450 350
Max power consumption/W/M2 1000 950 700
Size of cabinet/mm 1024X768 960X960 1024X1024
Resolution of cabinet 128X96 96X96 64x64
Driving method 1/4 scan constant current 1/4 scan constant current Static constant current
Refresh rate Hz/S ≥1200 ≥1200 ≥1200
Luminance of white balance ≥6000 nits ≥7500 nits ≥7000 nits
Operation of Environmental Temperature/℃ below 30 to above 50
IP rating Front,IP65;Rear,IP43
Working voltage 110-220 VAC/+/- 10%
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment 4096 levels of each color(manually),100 levels of each color(automatically)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Linsn / Nova(sending card,receiving cards and Hubs)
Average of non-failure life >50,00h
Life span >100,000h
Functionless dot rate <0.0001





Main advantages:



1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;


2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;

3. Module surface flatness ± 0.2mm, the entire screen has good flatness;

4. High uniformity display color;

5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.

6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate





Applications:


Commercial advertising: Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc

Programmable Outdoor Full Color Led Signs 1R1G1B IP65 256x256mm Module Size 0







Package:



Flight case and Fumigation-Free wooden case
