EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC

EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC

  • EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC
  • EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC
  • EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC
  • EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC
EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC , CE , RHos
Model Number: PH10mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight case or Fumigation-Free Wooden Case
Delivery Time: 15~20 Working days
Payment Terms: L, T/T, Western Union, MoneyGram
Supply Ability: 2000SQM/Month
Contact Now
Detailed Product Description
Driving IC: MBI5124 LED Brand: EPISTAR
Color: Full Color Brightness: 8000CD/SQM
Display Function: Video, Text, Picture Control System: Linsn / Nova(sending Card,receiving Cards And Hubs)
High Light:

outdoor led advertising signs

,

full color programmable led signs

Advertising Media Outdoor Led Signs Video Wall , Full Color Led Message Board Signs



Main advantages:


1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;


2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;

3. Module surface flatness ± 0.2mm, the entire screen has good flatness;


4.High uniformity display color;

5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.

6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;


7. Using fishbone bus line greatly reduces the contact problem;

8. IP65 grade for high performance waterproof and dustproof capability;


9. -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.





Specifications:



                          Outdoor Fixed Installed Giant Advertising Media LED Displays
Main Pitch/mm P8 P10 P16

Module size/mm 256x128 160x160 256x256
Density of pixel/(dots/m2) 15,625 10,000 3,906
Pixel composition 1R1G1B 1R1G1B 1R1G1B
Led encapsulation SMD3535 DIP346 DIP346
Resolution of module 32x16 16X16 16X16
Optimum viewing distance ≥6 ≥10 ≥15
View angle / ° 140H,120V 110 H,60 V 110 H,60 V
Average power consumption/W/M2 500 450 350
Max power consumption/W/M2 1000 950 700
Size of cabinet/mm 1024X768 960X960 1024X1024
Resolution of cabinet 128X96 96X96 64x64
Driving method 1/4 scan constant current 1/4 scan constant current Static constant current
Refresh rate Hz/S ≥1200 ≥1200 ≥1200
Luminance of white balance ≥6000 nits ≥7500 nits ≥7000 nits
Operation of Environmental Temperature/℃ below 30 to above 50
IP rating Front,IP65;Rear,IP43
Working voltage 110-220 VAC/+/- 10%
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment 4096 levels of each color(manually),100 levels of each color(automatically)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Linsn / Nova(sending card,receiving cards and Hubs)
Average of non-failure life >50,00h
Life span >100,000h
Functionless dot rate <0.0001





Applications:


Commercial advertising: Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc



EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC 0







Package



Flight case and Fumigation-Free wooden case



EPISTAR Full Color Led Message Board Signs Advertising Media MBI5124 Driving IC 1
