Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks

Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks

Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
Product Details:
Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P6.25mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Cabinet Size:: 500mm * 500mm, 500mm * 1000mm Weight: 6.5Kg, 13Kg
Product Name: Concert Stage LED Display Application: Concert Stage
Refresh Rate: 3840Hz IP Rate: 43
Lifespan: 100000H Material: Aluminum Die-casting
High Light:

stadium led display

,

stage background led screen

Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks





Product features of Concert Stage LED Display:



1. Slim panel , Die casting aluminum technology ;



2. Super thin and lightweight , only 8Kg/panel , easy to install with handles and fast locks ;



3. Fluently video display ,no fliker with high refresh rate 2880 Hz ;



4. 500x500mm Die-casting aluminum panel , nice appearance and good quality ;



5. Seamless and flatness to ensure high quality video effect ;



6. No fan design , no noise .





Specification of Concert Stage LED Display :



Item Indoor
Fantasy Series 3.91mm 4.81mm 5.6mm 6.2mm
LED Configuration 1R1G1B SMD2020 Black 1R1G1B SMD2020 1R1G1B SMD3528 1R1G1B SMD3528
Module Size 250mm*250mm 250mm*250mm 250mm*250mm 250mm*250mm
Module resolution 64*64dots 52*52dots 44*44dots 40*40dots
Pixel Density 65536picels/m2 43264picels/m2 30976picels/m2 25600picels/m2
Brightness ≧1200cd/m2 ≧1200cd/m2 ≧1200cd/m2 ≧1500cd/m2
Panel Resolution 128*128dots 104*104dots 88*88dots 80*80dots
Power Consumption

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Driving Mode 1/16 1/13 1/11 1/10
Material Aluminum Die-casting
Refresh Rate 2880HZ
Gray Scale 65536level
Viewing Angle(H/V) 140°/140°
Panel Size/Weight 500*500*75mm/6.5kg
IP Rating IP3X
Operating Temperature -20℃-60℃
Operating Humidity 10%-90%RH
Lifespan 10000hrs at 50% brightness
Control System Novastar/Linsn





Supply Ability of Concert Stage LED Display :



5000 Square Meter/Square Meters per Month





FAQ about Concert Stage LED Display:

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q8: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.







Product features :



1. High quality LED chip and high anti-static electricity capacity.



2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.





Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks 0
