SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz

SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz

SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz
SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz
SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz
Product Details:
Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P6mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Cabinet Size:: 500mm * 1000mm Weight: 13Kg
Product Name: SMD Stage LED Display Scan Mode: 1 / 16 Scan
Refresh Rate: 3840Hz IP Rate: 43
Brightness: 1300CD/SQM Material: Die Casting Aluminum
High Light:

stadium led display

,

led backdrop screen

SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz



Description of SMD Stage LED Display

1) Video play: it can play video programs in video camera, VCD, DVD and LD; it can also play files of different formats, such as AVI, MOV, MPG, DAT and VOB; it has three display formats, namely, VGA+VIDE, Video and VGA;

2) Information release: it can display a variety of computer information, graphs, two-dimensional animation and three-dimensional animation; it has lots of display methods, such as rolling, lead-in, lead-out, up shift, left shift and circulation; font, character size, letter and speed can be set randomly;

3) Network function With the network interface, it can be connected with the Internet to play information on the Internet at the same time; display screens at different places can be centralizedly controlled through Internet according to customers’ requirements, and “VPM+broadband” may be adopted for remote control.





Specifications of the Stage LED Display:



Pixel Pitch 3.91mm
Pixel Density 65536dots/sqm
Color Configuration 1R1G1B
LED Package SMD2121
Module Size 250mm x 250mm
Module Resolution 64dots x 64dots
Drive Mode 1/16 Scan
Cabinet Material Die casting Aluminum
Led Color Black
Standard Cabinet Size 500mm x 500mm
Cabinet Weight 7KG
Brightness ≥1300 cd/sqm, adjustable by software
Viewing Distance 4m-40m
Viewing Angle H: 140°; V:120°
Refresh Rate 1500HZ, adjustable by software
Frame Rate 120frame/s
Grey Scale 16.7M colors(Synchronized)
Color Temperature R.G.B brightness 256 level adjustable
Power Input AC110V/ 220V ±10%, 50HZ
Max Power Consumption 800W/sqm
Ave. Power Consumption 300W/sqm
Storage Temperature -30℃~+70℃
Working Temperature -20℃~+50℃
Blind Spot Rate <1/10000
MTBF >10,000 Hours
Life Span >100,000 Hours
Waterproof Level IP43
Operating Humidity 10%~90% RH
Control Method Synchronous, Asynchronous, 3G,WIFI,USB
PC Display Resolution 1280x1024
Control PC With DVI Graphic card
Operating System Win 98, Win2000, XP, Win7, Win8,Win10
Video Signal Mode RF, S-Video, RGB, RGBHV, YUV, YC etc
Certificate CE, RoHS





Product Function of SMD Stage LED Display :



Stable performance,wide applicability, high brightness, superb performance/price ratio.

  • High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown.
  • Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.



Features:

  • Best visualization
  • Longer service life
  • Nice look
  • Perfect cabinet size for high definition: :5760mm*576mm*80mm
  • Both installation handle and lifting handle are offered.
  • Mask protection with good reliability.
  • Seamless splicing, perfect in viewing effect.use led module size 192mmX192mm.
  • Low cost on maintenance.
  • Bright color, no light refection and great display effect.
  • Not easy to be distorted and good consistence.
Service:

As LED screen is not a simple commodity"purchase then end",service whatever before purchase or after sales is very important.Our service contains:

Pre-sale services
1. On-site investigation
2. Design
3. Solution provider
4. Advisory service

In-sale services
1. Installation guide
2. Debugging

After-sale services
1. Factory technical training
2. Onsite inspection
3. Calibration
4. Remote support
5. Engineering consulting


FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.



SMD Stage LED Display P6mm , Outdoor LED Display High Resolution 3840Hz 0
