Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection

Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection

Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection
Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection
Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection
Product Details:
Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P4mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Cabinet Size:: 512mm * 512mm Other Nama: Slim LED Backdrop Screen
Display Function: Video Scan Mode: 1 / 8 Scan
Refresh Rate: 3840Hz IP Rate: 43
Brightness: 1500CD/SQM Material: Die Casting Aluminum
High Light:

stage background led screen

,

led backdrop screen

P4mm Indoor Slim Rental Stage LED Display With Long Life Span , Super Clear Vision





Features of Slim LED Backdrop Screen:

  • Best visualization
  • Longer service life
  • Nice look
  • Perfect cabinet size for high definition: :5760mm*576mm*80mm
  • Both installation handle and lifting handle are offered.
  • Mask protection with good reliability.
  • Seamless splicing, perfect in viewing effect.use led module size 192mmX192mm.
  • Low cost on maintenance.
  • Bright color, no light refection and great display effect.
  • Not easy to be distorted and good consistence.



Product Function of Slim LED Backdrop Screen :



Stable performance,wide applicability, high brightness, superb performance/price ratio.

  • High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown.
  • Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.



Service:



  1. Two-year warranty for the entire system, except human factors and force majeure Guarantee.
  2. One of the year the quality, maintenance of life, and to ensure the maintenance time in the contract.
  3. The warranty period: solving problems for users through telephone, fax or email. Update the software for free.
  4. As to product quality problems caused by the design, manufacturing, technology installation, equipment, replacement and maintenance are free. System damage caused by force majeure (flood, fire, earthquake, war, and so on) as well as users) artificial disturbance (construction, cleaning) should be coordinated by the two parties to résoudre.Entretien
  5. Life long for the system: after the warranty, we charge only the cost of equipment.



Technical Parameters of Slim LED Backdrop Screen



Technical Parameters of P4 LED screen indoor.
PROJECT P4 LED indoor display screen
Pixel pitch 4mm
Pixel density 62500 Pixels/sqm
Module size(W*H) 128 W(mm) 128 H(mm)
Module pixels(W*H) 32 Pixels(W) 32 Pixels(H)
Pixel configuration 1Red 1Green 1Blue
Drive mode constant current driving 1/16 scan
LED lamp type SMD3528(Black body)
Cabinet size(W*H*D) 512 W(mm) 512 H(mm)
Cabinet resolution 128 Pixels(W) 128 Pixels(H)
Color scale 65,536 degree
View angle(H/V) 140/120 degree
Brightness (White balance) ≥1200cd/sqm.
Power consumption(one cabinet) Max:1100W/sqm. Average:400W/sqm.
Operating Voltage AC100V±10% or 220V ±10%; 50---60HZ
Net weight 39 Kg/M 2 for Iron cabinet
Operating temperature -20°C----+50°C (Customized power supply:-45°C---+60°C)
Operating humidity 10%_95%RH
Life time ≥100,000hours
MTBF 5,000 hours
Whole Display Flatness ≤0.3mm Juncture
Frame frequency >60 Hz/s
Refresh rate ≥800Hz /s
Control distance 100m (without repeater), single mode fiber:20km, multi mode fiber: 500m
Power 110V/220V±15% 50--60Hz
LED control system LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable
Operating system Windows 2000 / Windows Xp / Windows 7
Protections for outdoor display IP43
Maintenance way Rear Access
Accepting signal with video processor

PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI







FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A:The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q8: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.



Slim LED Backdrop Screen P4 Long Life Span Super Clear Vision Mask Protection 0
