|Place of Origin:||Shenzhen, China|
|Certification:||CCC, CE, ROHS|
|Model Number:||PRO - P6.25|
|Minimum Order Quantity:||Negotiation|
|Packaging Details:||flight case; export wooden case|
|Delivery Time:||15~25 working days|
|Payment Terms:||T/T, Western Union, MoneyGram|
|LED Brand:||NATIONSTAR||Grey Scale:||16Bits|
|Material:||Aluminum||Working Voltage:||AC100V - 240V|
|Cabinet Size:||500mm * 500mm , 500mm * 1000mm||Tube Chip Color:||Full Color|
event screen hire,
large outdoor screen hire
P6 LED Rental Display , LED Display Screen Rental Full Color Wide Viewing Angle
Features of LED Rental Display
1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.
2. Thin cabinet: the thickness is only 6.5 CM, the space of the screen is small , and the entire screen will be more beautiful.
3. Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon effectively. The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.
5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
6. Concave and convex setup support: client can asselbly any shape of the led wall display to make different show effect compare with common led display panel.
Special Features of LED Rental Display :
1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
2. Viewing angle of 140 degrees or more, multi direction viewing display effect is consistent;
3. Integrated blanking circuit, effectively eliminate the ghost line;
4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.
5. Support All Media Format and Display Mode:
DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.
Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet.
Advantages of Features of LED Rental Display:
Use of Special heat dissipation structure make excellent heat dissipation, Quiet operation without fans.High refresh/High contrast/High grayscale/ Gorgeous picture showing Ultra-wide viewing angle give you the largest screen viewing area.Die-cast aluminum cabinet design light and easy to transport, good flatness and seamless
Detail Specifications of Features of LED Rental Display:
|Physical Parameter||Pixel Configuration||1R1G1B|
|Pixel Pitch (mm)||6.25|
|Pixel Matrix per m2 (dots)||25600|
|Pixel Matrix per Module||40*40|
|Pixel Matrix per Panel||80*80 / 80*160|
|Module Dimensions (L*W) / (mm)||250*250|
|Module Quality per Cabinet||2*2 / 2*4|
|Panel Dimension (L*W*H) / (mm)||500*500*78 / 500*1000*78|
|Panel Material||Die-Casting Aluminum|
|Panel Weight (Kg)||6.5 / 13|
|Electronic Parameter||Color Grayscale (Bit)||16|
|Gray Scale per Color (Level)||65536|
|Refresh Rate (Hz)||1920|
|Frame Frequency (Hz)||50/60|
|Signal Transmission Distance (m)||CAT5 cable:<100m；Single mode fiber:<10km|
|Optical Parameter||Brightness (cd/m2)||≥5000|
|Color Temperature (K)||6500-7500|
|Optimal Horizontal Viewing Angle (°)||160|
|Optimal Vertical Viewing Angle||160|
|Electrical Parameter||AC Input Voltage (V)||100~240|
|AC Input Frequency (Hz)||50/60|
|AC Input Power Maximum Value (W/m2)||800|
|AC Input Power Typical Value (W/m2)||300|
|Circumstance Parameter||Storage Temperature (℃)||-40~+60|
|Operating Temperature (℃)||-20~+50|
|Storage Humidity (RH)||10%~90%|
|Operating Humidity (RH)||10%~90%|
|IP Rating (Front / Rear)||IP65 / IP63|
|Lifrtime Typical Value (Hrs)||100,000|
|Installation type||Cabinet Installation Type||Rental|
|Maximum Number of Panel for Lifting||12 / 6|
1. Your inquiry about our products or the price will be replied within 8 hours.
2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.
4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
Application of Features of LED Rental Display
Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on .
