Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate

Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate

    • Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate
    • Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate
    • Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate
  • Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: PASSION
    Certification: CCC, CE, ROHS
    Model Number: P2.5mm, P3.91mm, P4.81mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Flight case, export wooden case
    Delivery Time: 10-20 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 1000sqm/month
    Contact Now
    Detailed Product Description
    Usage: Indoor Meterial: Aluminum
    Refresh Rate: 3840 Display Function: Video
    Led Chip: Nationstar Tube Chip Color: Full Color
    Warranty: 2 Years Cabinet Size: 500x500mm/500*1000mm
    High Light:

    indoor advertising boards

    ,

    indoor advertising display

    Slim Rental Indoor Full color Led Advertising Screen Aluminum Cabinet High Refresh Rate



    Product Specifications of Indoor Full Color LED Display:



    indoor curved p2.976 p3.91 p4.81 p5.95 p6.25 led wall waterproof LED module p2.976 p3.91 p4.81 p5.95 p6.25 indoor curved rental stage ultra slim led screen for concert


    With the light cabinet and good material , installation easily .



    Description of Indoor Full Color LED Display:

    1. Usage : Different indoor environment, hotel, night club,shopping mall, meeting room etc

    2. Installation : Mounted-wall, standing on floor. hanging etc

    3. Control : Contolled by your computer ,own equipment.;

    4. Connection : Connected to your computer,Camera or own equipment.

    5. Maintenance: Enough Free spare parts for replacement.,Front service/ Rear service



    Main features of Indoor Full Color LED Display:

    1. SMD3 in 1 technology widens the viewing angle greatly and makes the screen's surface even flatter.
    2. Flatness tolerance of the whole screen is < 0.15 mm, which thoroughly eliminates the mosaic effect.
    3. The screen displays delicate and vivid pictures through synchronous adjustment of color and brightness.
    4. High contrast and high refresh rate help the LED display's image be rendered without any delay, and without leaving any kind of streaks or trails.
    5. Compatible with a variety of signal source inputs, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP, etc.



    Parameter Value
    Physical Parameter Pixel Configuration 1R1G1B
    Pixel Pitch (mm) 2.5
    Pixel Matrix per m2 (dots) 160000
    Pixel Matrix per Module 64*64
    Pixel Matrix per Panel 192*192
    Module Dimensions (L*W) / (mm) 160*160
    Module Quality per Cabinet 3*3
    Panel Dimension (L*W*H) / (mm) 480*480
    Panel Material Iron / Aluminum
    Panel Weight (Kg) 6
    Electronic Parameter Color Grayscale (Bit) 14
    Gray Scale per Color (Level) 16384
    Refresh Rate (Hz) 1280
    Driving Type 1/32
    Frame Frequency (Hz) 50/60
    Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
    Optical Parameter Brightness (cd/m2) ≥1000
    Color Temperature (K) 6500-7500
    Color Contrast 4000:1
    Optimal Horizontal Viewing Angle (°) 160
    Optimal Vertical Viewing Angle 160
    Electrical Parameter AC Input Voltage (V) 100~240
    AC Input Frequency (Hz) 50/60
    AC Input Power Maximum Value (W/m2) 1100
    AC Input Power Typical Value (W/m2) 400
    Circumstance Parameter Storage Temperature (℃) -40~+60
    Operating Temperature (℃) -20~+50
    Storage Humidity (RH) 10%~90%
    Operating Humidity (RH) 10%~90%
    IP Rating (Front / Rear) IP63 / IP54
    Lifrtime Typical Value (Hrs) 100,000
    Installation type Cabinet Installation Type Fixed
    Maximum Number of Panel for Lifting 12



    Product Name
    p2.976
    p3.91
    p4.81
    p5.95
    p6.25
    Module size(mm)
    250*250
    Color
    full color
    Brightness
    >2000
    Refresh rate
    >1920 or 3840
    Pixel Density
    112896
    65536
    43264
    28235
    25600
    Working Voltage
    110-240V
    Cabinet size
    500*500mm and 500X1000mm die casting aluminum cabinet



    Application of Indoor Full Color LED Display:
    Indoor HD led display is also called led TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 480 x 480mm, Die-casting aluminum structure with high precision and cooling effect.
