Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness

Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness

    • Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness
    • Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness
    • Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness
  • Full Color Programmable RGB Led Message Sign 960*960mm 6000CD/Sqm Brightness

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: PASSION
    Certification: CE , ROSH
    Model Number: P6mm, P8mm P10mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Wooden case or Flight case
    Delivery Time: 15 days after deposit payment arrival
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 2000SQm/Month
    Contact Now
    Detailed Product Description
    Usage: Outdoor Cabinet Size: 960mm * 960mm
    Working Voltage: AC100-240V Display Function: Video, Flash, Text
    Brightness: 6000CD/sqm Refresh Rate: 3840Hz
    High Light:

    outdoor led advertising signs

    ,

    full color programmable led signs

    960*960mm 6000CD/Sqm Brightness Full Color Programmable RGB Outdoor Led Message Sign


    All our module chip are from Taiwan Epistar. We guarantee our high quality from the first step !



    All our modules are strictly tested one by one !



    We have special workers to make sure every module works well !



    Our Services

    1. Your inquiry related to our products or price will be replied in 8hrs.
    2. OEM & ODM,any your customized lightings we can help you to design and put into product.
    3. Distributoership are offered for your unique design and some our current models.
    4. Protection of your sales area,ideas of design and all your private information.
    5. Best cost performance and perfect service before and after sales.




    Description:



    1. Advanced SMT encapsulation technology ensure the led lamps in good uniformity,and wide view angle,lower power consumption,energy-saving more than 30%

    2. Good waterproof, IP65 grade, Anti-corrosion,Antifogging,suit for outdoor different weather condition,keep long life time.

    3. High pixel density,High brightness and Long view distance,can be seen from far away 100 meters

    4. Good protection with soft mask and thick bongrace,avoid to be broken and to hurt sportsmen

    5. Brightness can be adjusted automatically according to different surrondings,
    can be set to open and close the screen on fixed automatically

    6. Widely used for commercial advertising, match live broadcasting,sport rebroadcast, company logo, for fixed or for rental use,panel size can be customized according different requirements.




    Product Spefications:

    LED Module Pitch/mm PH10
    Module size/mm 320*160
    Density of pixel/(dots/m2) 10000
    Pixel composition 1R1G1B
    Led encapsulation SMD3535
    Resolution of module 32*16
    LED Screen Optimum viewing distance 8~100M
    View angle H:±120°;V±60°
    Average power consumption 300W/sqm
    Max power consumption 800W/sqm
    Module quantity 3 * 6pcs
    Size of cabinet/mm 960*960
    Resolution of cabinet 96*96
    Cabinet Material Iron Cabinet (Aluminum Cabinet optional)
    Weight of cabinet 55Kg
    Driving method 1/2scan constant current
    Frame frequency / Hz/S ≥60
    Refresh frequency / Hz/S 2000
    Brightness 6500cd/m2
    Operating temperature –25C°~65C°
    Storage temperature –40C°~70C°
    Operation humidity 10%-90%
    Storage humidity 10%-90%
    IP Rrating (Front/Rear) IP65/ IP54
    Working vlotage AC220V / AC110V ±10%
    Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
    Brightness adjustment 256 levels of each color(manually)
    Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control system linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
    Average of non-failure life ≥50,00h
    Life span ≥100,000h
    Functionaless dot rate ≤0.0001
    Control distance CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km
