1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate

1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate

  • 1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate
  • 1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate
  • 1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate
  • 1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate
1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CE ,ROSH
Model Number: P16mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: wooden case
Delivery Time: 15 days after deposit payment arrival
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 2000SQm/Month
Contact Now
Detailed Product Description
LED Type: DIP346 Materail: Iron Or Aluminum
Product Name: Outdoor Advertising LED Display Working Voltage: AC100-240V
Panel Dimension: 1024mm * 768mm Driving IC: MBI5124
Brightness: 6000CD/sqm Refresh Rate: 1920Hz
High Light:

large outdoor led display screens

,

outdoor full color led display

1024x768 Outdoor Advertising LED Display Screen RGB Full Color 1280 Refresh Rate




Application Area of Outdoor Advertising LED Display Screen :


Public place:bus,subway, train station, airport, book store, park, exhibtion hall, stadium, museum,buildings, highway, school, meeting room, wedding;

Budiness orginazations: supermarket, shopping mall, hotels, restaurant,hospital;

Financial Orginazations: bank, insurance company, stock company, pawnshop;

Entertainment: theater, clubs, bars,KTV, internet bars;





Detail Specifications of the Outdoor Advertising LED Display P16mm model:



Physical Parameter Pixel Configuration 1R1G1B
Pixel Pitch (mm) 16
Pixel Matrix per m2 (dots) 3906
Pixel Matrix per Module 16*16
Pixel Matrix per Panel 64*48
Module Dimensions (L*W) / (mm) 256*256
Module Quality per Cabinet 4*3
Panel Dimension (L*W) / (mm) 1024*768
Panel Material Iron / Aluminum
Panel Weight (Kg) 45
Electronic Parameter Color Grayscale (Bit) 16
Gray Scale per Color (Level) 16384
Refresh Rate (Hz) 1280
Driving Type 1/4
Frame Frequency (Hz) 50/60
Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
Optical Parameter Brightness (cd/m2) ≥6500
Color Temperature (K) 6500-7500
Color Contrast 4000:1
Optimal Horizontal Viewing Angle (°) 160
Optimal Vertical Viewing Angle 160
Electrical Parameter AC Input Voltage (V) 100~240
AC Input Frequency (Hz) 50/60
AC Input Power Maximum Value (W/m2) 1000
AC Input Power Typical Value (W/m2) 350
Circumstance Parameter Storage Temperature (℃) -40~+60
Operating Temperature (℃) -20~+50
Storage Humidity (RH) 10%~90%
Operating Humidity (RH) 10%~90%
IP Rating (Front / Rear) IP65 / IP63
Lifrtime Typical Value (Hrs) 100,000
Installation type Cabinet Installation Type Fixed
Maximum Number of Panel for Lifting 6





Product Advantages of Outdoor Advertising LED Display Screen :



1. Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;



2. Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle, at this range, no picture change, no color excursion;



3. To pictures and character, have clear, exquisite and real display effect;



4. High intensity and can be adjusted, so can meet the request of the customers according to the

application environment;



5. Can repair each led lamps, so the cost of maintain is lower, and easy to repair





Trade Articles of Outdoor Advertising LED Display Screen :



1) Trade terms: FOB,CIF,EXW

2) Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery

4) Production lead time less 20 sqm: 8-15days, more than 50 sqm:20days. Sample can be deliveried within 3days
5) Shipping: by sea,by air and by express delivery
6) Shipping port: Shenzhen, Mainland China
