Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness

Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness

  • Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness
  • Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness
Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC, CE, ROHS
Model Number: P4mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight case, export wooden case
Delivery Time: 10-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000sqm/month
Contact Now
Detailed Product Description
Color Contrast: 4000:1 Panel Weight (Kg): 38
Cabinet Size: 768mm * 768mm Refresh Rate: 1280
Display Function: Video Working Voltage: AC 100 ~ 240V
High Light:

led screen video wall

,

rgb led video wall

Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness





Competitive advantages:

1. We are led screen manufacturer for many years, quality is guaranteed.
2. Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level.
3. Professional sales and technical team of 15 people to ensure perfect results.
4. Customer requirements are fundamental, we make different solutions accroding different requirements of customers.





Description:

1. personalized and complete solution for your case
2. factory price and good quality
3. convenient and fast installation ,easy maintenance
4. 2 years wanrranty





LED Modules:



Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness 0





Product Specifications:



Parameter Value
Physical Parameter Pixel Configuration 1R1G1B
Pixel Pitch (mm) 4
Pixel Matrix per m2 (dots) 62500
Pixel Matrix per Module 64*32
Pixel Matrix per Panel 192*192
Module Dimensions (L*W) / (mm) 256*128
Module Quality per Cabinet 3*6
Panel Dimension (L*W) / (mm) 768*768
Panel Material Iron / Aluminum
Panel Weight (Kg) 38Kg
Electronic Parameter Color Grayscale (Bit) 14
Gray Scale per Color (Level) 16384
Refresh Rate (Hz) 1280
Driving Type 1/16
Frame Frequency (Hz) 50/60
Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
Optical Parameter Brightness (cd/m2) ≥2000
Color Temperature (K) 6500-7500
Color Contrast 4000:1
Optimal Horizontal Viewing Angle (°) 160
Optimal Vertical Viewing Angle 160
Electrical Parameter AC Input Voltage (V) 100~240
AC Input Frequency (Hz) 50/60
AC Input Power Maximum Value (W/m2) 900
AC Input Power Typical Value (W/m2) 300
Circumstance Parameter Storage Temperature (℃) -40~+60
Operating Temperature (℃) -20~+50
Storage Humidity (RH) 10%~90%
Operating Humidity (RH) 10%~90%
IP Rating (Front / Rear) IP43 / IP31
Lifrtime Typical Value (Hrs) 100,000
Installation type Cabinet Installation Type Fixed
Maximum Number of Panel for Lifting 8





Application of HD LED screen:
Indoor HD led display is also called led TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 400 x 300mm, Die-casting aluminum structure with high precision and cooling effect.



Full Color Indoor LED Video Wall , 4mm LED Video Wall 2000 Nits Brightness 1
