High Definition LED Display Board Optical Visual Design Quick Locking Mechanism

High Definition LED Display Board Optical Visual Design Quick Locking Mechanism

    • High Definition LED Display Board Optical Visual Design Quick Locking Mechanism
    • High Definition LED Display Board Optical Visual Design Quick Locking Mechanism
    • High Definition LED Display Board Optical Visual Design Quick Locking Mechanism
  • High Definition LED Display Board Optical Visual Design Quick Locking Mechanism

    Product Details:

    Place of Origin: Shenzhen , China
    Brand Name: PASSION
    Certification: CCC , CE , ROHS
    Model Number: P1.25mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Export Wooden Case & Flight Case
    Delivery Time: 10 - 20 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 2000SQM/Month
    Contact Now
    Detailed Product Description
    Usage: Indoor Grey Scale: 16 Bits
    Working Voltage: AC 100-240V Material: Die Casting Aluminum
    Lifespan:: 100000 Hours Referesh Rate: 3840Hz
    High Light:

    high resolution led display

    ,

    high definition led display

    High Definition LED Display Board Optical Visual Design Quick Locking Mechanism



    Application of HD LED Display:


    PASSION LED P1.25 indoor HD LED display is also called HD LED TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 600 x 337.5mm, Die-casting aluminum structure with high precision and cooling effect.



    Natural Color
    16bits Gray processing techology,with 65536 grayscale,excessive nature,according to the video picture of extremely fine texture,looked more comfortable.

    High definition display
    It delivers a truly amazing pciture in every details with extrodinary pixels producing an image that is HD quality in an LED screen

    Ultra wide angle of view
    Ultra wide angle of view,from any perspective images are clear natural,to experience the great subversive viewing experience

    Top-lever brightness control
    Expansion of brightness adjustment range increase the brightness and contrast ratio of picture. This function can fully perform delicate change of brightness,so it can present a vivid clear picture to audience.





    16:9 Design and Good Uniformity

    16:9 design. Cabinet's 16:9 resolution is specialized for command center. Perfect replacement for LCD display.
    Die cast aluminum cabinet, guarantee you a flat and seamless screen.
    Good uniformity. Dot-to-dot correction technology provide you pure image with great gradation.


    Pixel Pitch: PH1.25mm
    Cabinet Size: 600 x 337.5 x 85mm
    1. Gapless installation, wider viewing angle, good color uniformity
    2. Soft images,green and environmental protection
    3. High refresh rate, remove ghost without trailing
    4. Locating slot work with dowel pin to ensure good flatness
    5. 16bit gray scale processing, color expression more naturally

    Detail Specifications of the HD LED Display:



    Pixel Configuration

    SMD1010

    Pixel pitch(mm)

    1.25mm

    Pixel density(dots/m2)

    640000

    Module resolution(W×H)

    160×135

    Module size (mm)

    200(W)×168.75(H)

    Module weight (kg)

    0.8

    Maximum power consumption of the module(W)

    40

    Module of cabinet (W×H)

    3×2

    Cabinet resolution(W×H)

    480×270

    Cabinet size (mm)

    600(W)×337.5(H)×86(D)

    Cabinet area(m2)

    0.2

    Cabinet weight (kg)

    7.8

    Cabinet level up degree(mm)

    ≤0.2

    Maintenance mode

    Front/Rear

    Cabinet raw material

    Die-casting aluminum

    Single-point brightness correction

    YES

    Single - point color correction

    YES

    White Balance Brightness (nits)

    ≥800(6500K)

    Color Temperature (K)

    3200—9300 (adjustable)

    Viewing Angle (Horizontal / Vertical)

    160/160

    Deviation of center distance of light - emitting

    <3%

    Brightness / chromaticity uniformity

    ≥97%

    Contrast

    4000:1

    Peak power consumption (W / m2)

    800

    Average power consumption (W / m2)

    250

    Power supply requirements

    AC90~264V,frequency 47-63(Hz)

    Frame rate (Hz)

    50&60

    Drive mode

    Constant drive,1/27

    Grayscale level

    65536

    Refresh rate (Hz)

    ≥3840

    Number of color processing bits

    16bit

    Video playback capabilities

    2KHD,4KHD

    Operating temperature / humidity range (℃ / RH)

    -20 – 60 / 10%-85%RH

    Storage temperature / humidity range (℃ / RH)

    -20 – 60 / 10%-85%RH

    Applicable standards

    CCC,CE,RHos
