P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance

P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance

P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance
P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance
P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance
Product Details:
Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P6mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Cabinet Size:: 576mm * 576mm Weight: 6Kg
Display Function: Video Scan Mode: 1 / 16 Scan
Refresh Rate: 3840Hz IP Rate: 43
Brightness: 1500CD/SQM Product Name: Stage LED Display
High Light:

stadium led display

,

led backdrop screen

P6 Stage LED Display Aluminium Alloy Cabinet Seamless Splicing Low Maintenance





Product Function of Stage LED Display:



Stable performance,wide applicability, high brightness, superb performance/price ratio.

  • High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown.
  • Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.



Features of Stage LED Display:

  • Best visualization
  • Longer service life
  • Nice look
  • Perfect cabinet size for high definition: :5760mm*576mm*80mm
  • Both installation handle and lifting handle are offered.
  • Mask protection with good reliability.
  • Seamless splicing, perfect in viewing effect.use led module size 192mmX192mm.
  • Low cost on maintenance.
  • Bright color, no light refection and great display effect.
  • Not easy to be distorted and good consistence.



Technical Parameters of Stage LED Display



Parameters
Module NO. Item Parameter
1 Module Model P6(Indoor)
2 Pixel pitch 6mm
3 Module dimension 192mm*192mm
4 Module density 27780pixel/sqm
5 Module resolution 32*32dots
6 LED encapsulation SMD 3in1(3528)
7 Pixel configuration 1R1G1B

Cabinet 1 Dimension 576mm*576mm*80mm
2 Physical resolution 96*96dots
3 Module quantity 9PCS
4 Weight 9kg/PCS
5 Material Die-casting aluminum
6 Driving method Constant current+1/16 scan
7 Brightness ≥1200nits
8 Max power consumption 350W/SQM
9 Average consumption 200W/SQM
10 Frame frequency 60HZ
11 Refresh frequency >1200HZ
12 Gray level 1024~16384
13 Input Voltage AC100-120V AC200-240V
14 Power supply 5V/40A 1 PCS
15 Viewing angle(H/V) 120°/ 120°
16 viewing distance 5m-100m
17 Working environment Temperature: -20°C~ 60°C
Humidity:10%~90%RH
18 Control system Synchronous or Asynchronous Control system
19 Display function Videos
20 Certificate CE Certification





Service:



  1. Two-years warranty for the entire system, except human factors and force majeure Guarantee.
  2. One of the year the quality, maintenance of life, and to ensure the maintenance time in the contract.
  3. The warranty period: solving problems for users through telephone, fax or email. Update the software for free.
  4. As to product quality problems caused by the design, manufacturing, technology installation, equipment, replacement and maintenance are free. System damage caused by force majeure (flood, fire, earthquake, war, and so on) as well as users) artificial disturbance (construction, cleaning) should be coordinated by the two parties to résoudre.Entretien
  5. Life long for the system: after the warranty, we charge only the cost of equipment.

FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q8: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.
