500*1000mm Aluminum Led Video Display Panel Rental Stage Background Screen 3840Hz

500*1000mm Aluminum Led Video Display Panel Rental Stage Background Screen 3840Hz

500*1000mm Aluminum Led Video Display Panel Rental Stage Background Screen 3840Hz
500*1000mm Aluminum Led Video Display Panel Rental Stage Background Screen 3840Hz

Product Details:

Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P3.91mm

Payment & Shipping Terms:

Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Other Name: Stage LED Display Panel Weight: 28Kg/SQM
Display Function: Video, Picture Application: Indoor And Outdoor Stage
Material: Die Casting Aluminum Referesh Rate: 3840Hz
High Light:

stadium led display

,

stage background led screen

500*1000mm Aluminum Led Video Display Panel Rental Use Stage Background Led Display



Product features of RGB Stage LED Display:



1. High quality LED chip and high anti-static electricity capacity.



2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.



Supply Ability of RGB Stage LED Display :



5000 Square Meter/Square Meters per Month



Specification of RGB Stage LED Display:



Indoor slim rental P3.91mm LED screen (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 1000mm)
LED Module Pitch/mm PH3.91
Module size/mm 250*250
Density of pixel/(dots/m2) 65536
Pixel composition 1R1G1B
Led encapsulation SMD2121 3 IN 1
Resolution of module 64*64
LED Screen Optimum viewing distance 3~38M
View angle H:±160°;V±120°
Average power consumption 300W/sqm
Max power consumption 800W/sqm
Module quantity 2* 4pcs
Size of cabinet/mm 500*1000
Resolution of cabinet 128*256
Cabinet Material die-casting aluminum cabinet
Weight of cabinet 13Kg
Driving method 1/16 scan constant current
Frame frequency / Hz/S ≥60
Refresh frequency/ Hz/S 1920
Brightness 1000cd/m2
Operating temperature –20C°~60C°
Storage temperature –40C°~70C°
Operation humidity 10%-90%
Storage humidity 10%-90%
IP Rrating (Front/Rear) IP43
Working vlotage AC110V ±10%
Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
Brightness adjustment 256 levels of each color(manually)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Novastar
Average of non-failure life ≥50,00h
Life span ≥100,000h
Functionaless dot rate ≤0.0001
Control distance CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km





FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q4: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.
