6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology

6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology

    • 6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology
    • 6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology
    • 6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology
  • 6000CD/SQM Brightness Outdoor Full Color LED Module 1/8 Scan With Smd3535 Technology

    Product Details:

    Place of Origin: Shenzhen , China
    Brand Name: PASSION LED
    Certification: CE , RHos
    Model Number: P6mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Carton or Wooden Case
    Delivery Time: 5 days sine the deposit arrival
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 10000PCS/month
    Contact Now
    Detailed Product Description
    Unit Size: 192mm * 192mm Pixel Pitch: 6mm, 8mm, 10mm
    LED Brand: NATIONSTAR LED Type: Outdoor 2727 SMD 3 In 1
    Brightness: 6000CD/SQM Refresh Rate: 3840Hz
    High Light:

    led video wall module

    ,

    led sign modules

    High Brightness Outdoor Full Color LED Module, Sign LED Modules 1/8 Scan Cost Effective





    Smd led module Quick Details:

    1. Waterproof led module with Smd3535 technology.

    2. 6500 cd/sqm High brightness & more than 1200Hz refresh rate.

    3. Factory price with good quality .

    4. 2 years warranty, lifetime maintance.

    Specifications:



    led module parameter
    Technical parameters UNIT parameters Values
    Pixel pitch mm 6
    module size mm 192*192
    Physical density dots/㎡ 27777
    Pixel configuration RGB 1,1,1
    Driving method   Constant current 1/8scan
    Led lamp Smd 3535
    module resolution dots 32*32
    Module weight Kg 0.315
    Module port   HUB75
    Module consumption W
    led display parameter
    Viewing angle Deg. H120 V120
    Viewing distance m 6-70
    Maximum power W/㎡ 900w
    Frame Frequency Hz ≥60
    Refresh frequency Hz ≥1200
    Equilibrium brightness cd/㎡ ≥6500
    Working environment temperature 0C -30~60
    Display working voltage VAC 220V±15%/110V±15%
    Gray scale/color   ≥16.7M color
    Input signal   RF S-Video RGB etc
    Control system   Nova/Linsn control system
    Mean free error time hours >5000
    life time hours >100,000
    Lamp failure frequency   <0.0001




    Features:

    Stable & Good quality: The quality of all our raw materias is stable, and our strick production qualithy control. so the result is good and we also have a good reputation in this industry

    Supporting many play files: videos, texts, pictures,graphics, PPT, Flashes and any sources
    from TV,VCD,DVD and so on

    HD & high refresh rate: the resolution for each led module is 32*32, so if the viewing
    distance is 6 meters or more, the effect is good enough for this model.

    Full color: adopt SMD3535 3 in 1 led lamps, excellent color performance and show the
    content of the video best and reality

    consumption; wide viewing angle, each module can be repaired, so it is easy and not will cost you much

    Advantages:

    1. We are led screen manufacturer for More than 10 years, we have rich experience in
    outdoor and indoor led display, quality is guaranteed



    2. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and
    trafficker at same level



    3. Professional sales and technical team of 35 people to ensure perfect results



    4. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make
    different solutions accroding different requirements of customers


    After-sell Service:

    Installation servive, usually we don't take charge of installing overseas, but we can
    provide technical support for you. if you need installation service, we can send our
    technicians to your country, but the customers need take charge of the cost

    Lifetime free maintenance and software upgrade service.

    we will reponse you in 24 houres if you have any question about the led screen,

    maintenance guidance and problem solution supplied in 48 hours.

    Providing customer with the loading program, so they can use as soon as they install the
    led screen,don't need to debug again

    Free technical training for how to use and handle the software.

    Customer satisfaction tracking report.




    FAQ:

    1. Except this model, are there any other models?
    yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10
    For outdoor led screen we have p5 p6 p8 p10

    2. Are you factory? and your warranty?
    yes we are 10 years factory, 2 years warranty and lifetime maintenance

    3. What's the function of your led screen?
    It supports videos, flash, WAV/MIDI, PPT, images and so on

    4. What's your delivery time?
    Wthin 7-21 days after we receiving deposit

    5. What's your package and shipping way?
    Goods are packed with wooden case or flight case; delivered by air or sea.
