6000CD Brightness LED Display Module Outdoor Full Color With NATIONSTAR Golden Wire

6000CD Brightness LED Display Module Outdoor Full Color With NATIONSTAR Golden Wire

6000CD Brightness LED Display Module Outdoor Full Color With NATIONSTAR Golden Wire
6000CD Brightness LED Display Module Outdoor Full Color With NATIONSTAR Golden Wire

Product Details:

Place of Origin: Shenzhen , China
Certification: CE , RHos
Model Number: P6mm, 8mm, 10mm

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton or Wooden Case
Delivery Time: 5 days sine the deposit arrival
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000PCS/month
Contact Now
Detailed Product Description
Unit Size: 192mm * 192mm, 160mm * 160mm Pixel Pitch: 6mm, 8mm, 10mm
LED Brand: NATIONSTAR LED Type: Outdoor 2727 SMD 3 In 1
Brightness: 6000CD/SQM Refresh Rate: 3840Hz
High Light:

led video wall module


led sign modules

6000CD Brightness Outdoor Full Color LED Module 1/2 Scan With NATIONSTAR Golden Wire LED



Smd led module Quick Details:

1. Waterproof led module with Smd3535 technology.

2. 6500 cd/sqm High brightness & more than 1200Hz refresh rate.

3. Factory price with good quality .

4. 2 years warranty, lifetime maintance.



led module parameter
Technical parameters UNIT parameters Values
Pixel pitch mm 6
module size mm 192*192
Physical density dots/㎡ 27777
Pixel configuration RGB 1,1,1
Driving method   Constant current 1/8scan
Led lamp Smd 3535
module resolution dots 32*32
Module weight Kg 0.315
Module port   HUB75
Module consumption W
led display parameter
Viewing angle Deg. H120 V120
Viewing distance m 6-70
Maximum power W/㎡ 900w
Frame Frequency Hz ≥60
Refresh frequency Hz ≥1200
Equilibrium brightness cd/㎡ ≥6500
Working environment temperature 0C -30~60
Display working voltage VAC 220V±15%/110V±15%
Gray scale/color   ≥16.7M color
Input signal   RF S-Video RGB etc
Control system   Nova/Linsn control system
Mean free error time hours >5000
life time hours >100,000
Lamp failure frequency   <0.0001



1. We are led screen manufacturer for More than 10 years, we have rich experience in
outdoor and indoor led display, quality is guaranteed


2. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and
trafficker at same level


3. Professional sales and technical team of 35 people to ensure perfect results


4. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make
different solutions accroding different requirements of customers



Stable & Good quality: The quality of all our raw materias is stable, and our strick production qualithy control. so the result is good and we also have a good reputation in this industry

Supporting many play files: videos, texts, pictures,graphics, PPT, Flashes and any sources
from TV,VCD,DVD and so on

HD & high refresh rate: the resolution for each led module is 32*32, so if the viewing
distance is 6 meters or more, the effect is good enough for this model.

Full color: adopt SMD3535 3 in 1 led lamps, excellent color performance and show the
content of the video best and reality

consumption; wide viewing angle, each module can be repaired, so it is easy and not will cost you much

After-sell Service:

Installation servive, usually we don't take charge of installing overseas, but we can
provide technical support for you. if you need installation service, we can send our
technicians to your country, but the customers need take charge of the cost

Lifetime free maintenance and software upgrade service.

we will reponse you in 24 houres if you have any question about the led screen,

maintenance guidance and problem solution supplied in 48 hours.

Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again

Free technical training for how to use and handle the software.

Customer satisfaction tracking report.



1. Except this model, are there any other models?
yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10
For outdoor led screen we have p5 p6 p8 p10

2. Are you factory? and your warranty?
yes we are 10 years factory, 2 years warranty and lifetime maintenance

3. What's the function of your led screen?
It supports videos, flash, WAV/MIDI, PPT, images and so on

4. What's your delivery time?
Wthin 7-21 days after we receiving deposit

5. What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air or sea.
