Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof

Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof

    • Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof
    • Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof
    • Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof
    • Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof
  • Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof

    Product Details:

    Place of Origin: SHENZHEN , CHINA
    Brand Name: PASSION
    Certification: CE ROHS
    Model Number: P2.9mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotioation
    Price: Negotiation
    Packaging Details: Flight Case & Wooden Case
    Delivery Time: 15 ~ 20 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 5000 square meter per month
    Contact Now
    Detailed Product Description
    Usage: Stage LED Brand: NATIONSTAR
    Display Function: Video Brightness: 1500CD/sqm
    Refresh Rate: 3840Hz IP Rate: 43
    Material: Aluminum Unit Cabinet Size: 500mm * 1000mm

    Curved Stage LED Display 1280x1024 Hang Up Installation IP43 Waterproof





    Description of Stage LED Display:



    Super Light and Thin

    8KG/panel with a depth of 70mm which is half of the depth of traditional LED screen,saving space and transportation cost.



    High Refresh Rate
    Refresh Rate≥3840, offering impressive visual effect.



    Noiseless
    Free of fans and air conditions, excluding noise and reducing power consumption.



    Fine and Smooth Picture
    Drive IC of high refresh rate and high grey scale to ensure stable picture and better visual effect of the screen.The latest horizontal-blanking circuit applied to completely eliminate phenomenon of blanking and smear.



    Seamless Splicing
    High conformity of picture without gap and information missing, realizing a seamless splicing display.



    Fast Installation and Dismantlement.





    Specifications of Stage LED Display:



    Pixel Pitch 3.91mm
    Pixel Density 65536dots/sqm
    Color Configuration 1R1G1B
    LED Package SMD2121
    Module Size 250mm x 250mm
    Module Resolution 64dots x 64dots
    Drive Mode 1/16 Scan
    Cabinet Material Die casting Aluminum
    Led Color Black
    Standard Cabinet Size 500mm x 500mm
    Cabinet Weight 7KG
    Brightness ≥1300 cd/sqm, adjustable by software
    Viewing Distance 4m-40m
    Viewing Angle H: 140°; V:120°
    Refresh Rate 1500HZ, adjustable by software
    Frame Rate 120frame/s
    Grey Scale 16.7M colors(Synchronized)
    Color Temperature R.G.B brightness 256 level adjustable
    Power Input AC110V/ 220V ±10%, 50HZ
    Max Power Consumption 800W/sqm
    Ave. Power Consumption 300W/sqm
    Storage Temperature -30℃~+70℃
    Working Temperature -20℃~+50℃
    Blind Spot Rate <1/10000
    MTBF >10,000 Hours
    Life Span >100,000 Hours
    Waterproof Level IP43
    Operating Humidity 10%~90% RH
    Control Method Synchronous, Asynchronous, 3G,WIFI,USB
    PC Display Resolution 1280x1024
    Control PC With DVI Graphic card
    Operating System Win 98, Win2000, XP, Win7, Win8,Win10
    Video Signal Mode RF, S-Video, RGB, RGBHV, YUV, YC etc
    Certificate CE, RoHS



    Applications

    Business Organizations Supermarket, large-scale shopping malls, star-rated hotels, travel agencies
    Financial Organizations Banks, insurance companies, post offices, hospital, schools
    Public Places Subway, airports, stations, parks, exhibition halls, stadiums, museums, commercial buildings, meeting rooms
    Entertainments Movie theaters, clubs, stages











    Packaging & Shipping


    We can use fly case or wooden case to pack the goods
