Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks

Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks

    • Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
    • Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
    • Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
    • Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
  • Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks

    Product Details:

    Place of Origin: SHENZHEN , CHINA
    Brand Name: PASSION
    Certification: CE ROHS
    Model Number: P6.25mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotioation
    Price: Negotiation
    Packaging Details: Flight Case & Wooden Case
    Delivery Time: 15 ~ 20 working days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 5000 square meter per month
    Contact Now
    Detailed Product Description
    Cabinet Size:: 500mm * 500mm, 500mm * 1000mm Weight: 6.5Kg, 13Kg
    Product Name: Concert Stage LED Display Application: Concert Stage
    Refresh Rate: 3840Hz IP Rate: 43
    Lifespan: 100000H Material: Aluminum Die-casting

    Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks





    Product features of Concert Stage LED Display:



    1. Slim panel , Die casting aluminum technology ;



    2. Super thin and lightweight , only 8Kg/panel , easy to install with handles and fast locks ;



    3. Fluently video display ,no fliker with high refresh rate 2880 Hz ;



    4. 500x500mm Die-casting aluminum panel , nice appearance and good quality ;



    5. Seamless and flatness to ensure high quality video effect ;



    6. No fan design , no noise .





    Specification of Concert Stage LED Display :



    Item Indoor
    Fantasy Series 3.91mm 4.81mm 5.6mm 6.2mm
    LED Configuration 1R1G1B SMD2020 Black 1R1G1B SMD2020 1R1G1B SMD3528 1R1G1B SMD3528
    Module Size 250mm*250mm 250mm*250mm 250mm*250mm 250mm*250mm
    Module resolution 64*64dots 52*52dots 44*44dots 40*40dots
    Pixel Density 65536picels/m2 43264picels/m2 30976picels/m2 25600picels/m2
    Brightness ≧1200cd/m2 ≧1200cd/m2 ≧1200cd/m2 ≧1500cd/m2
    Panel Resolution 128*128dots 104*104dots 88*88dots 80*80dots
    Power Consumption

    Avg:105w/panel

    Max:300w/panel

    Avg:105w/panel

    Max:300w/panel

    Avg:105w/panel

    Max:300w/panel

    Avg:105w/panel

    Max:300w/panel

    Driving Mode 1/16 1/13 1/11 1/10
    Material Aluminum Die-casting
    Refresh Rate 2880HZ
    Gray Scale 65536level
    Viewing Angle(H/V) 140°/140°
    Panel Size/Weight 500*500*75mm/6.5kg
    IP Rating IP3X
    Operating Temperature -20℃-60℃
    Operating Humidity 10%-90%RH
    Lifespan 10000hrs at 50% brightness
    Control System Novastar/Linsn





    Supply Ability of Concert Stage LED Display :



    5000 Square Meter/Square Meters per Month





    FAQ about Concert Stage LED Display:

    Q1. What is refresh rate?

    A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

    Q2. What is viewing angle?

    A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

    Q3. What are Pixel Pitch and Pixel Density?

    A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

    Q8: What is LED display?

    A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.







    Product features :



    1. High quality LED chip and high anti-static electricity capacity.



    2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.





    Concert Stage LED Display , LED Video Wall Screen Rental With Fast Locks
