Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm

Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm

    • Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm
    • Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm
    • Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm
    • Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm
  • Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: PASSION
    Certification: CCC, CE, ROHS
    Model Number: outdoor P10mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 10Sqm
    Price: Negotiation
    Packaging Details: flight case; export wooden case
    Delivery Time: 15~25 working days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 1000Sqm/month
    Contact Now
    Detailed Product Description
    Usage: Outdoor Materail: Aluminum
    IP Rate: 65 Working Voltage: AC100V - 240V
    Cabinet Size: 640mm * 640mm Display Function: Video
    Brightness: 5000CD/sqm Refresh Rate: 3840Hz

    Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm



    This series products are widely applied to stage show, concert, TV station, Brand presentation, stadium display screen and so on



    • Lightweight  The aluminum die-casting technology makes the single cabinet as light as 9KG.
    • Ultra thin  The thinnest point of the cabinet is only 75mm, making it easily to be fitted in small room.
    • Easy to install  No need of other tools. It takes 15 minutes for 2workers to finished 30 sqm installation.
    • High IP  The IP65 insures the reliable operation in severe environment.
    • Easy to maintain  No need to disassemble the whole screen for maintenance. Each component can be detach individually for that purpose.
    • Noiseless  The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.
    • Ghost canceling  Exquisite and clear picture quality with no ghost. Both upstream and downstream ghosts can be automatically canceled.
    • High refresh rate  38400Hz refresh rate to ensure the picture wrinkle-less, lineless and stable.
    • Low brightness and high gray scale  14Bit-16Bit gray scale to bring excellent performance when brightness reduced to 20%.





    LED Module Pitch/mm PH10
    Module size/mm 320*160
    Density of pixel/(dots/m2) 10000
    Pixel composition 1R1G1B
    Led encapsulation outdoor SMD 3 in 1 LED
    Resolution of module 32*16
    LED Screen Optimum viewing distance 8~100M
    View angle H:±120°;V±60°
    Average power consumption 300W/sqm
    Max power consumption 1000W/sqm
    Module quantity 2 * 4pcs
    Size of cabinet/mm 640*640
    Resolution of cabinet 64*64
    Cabinet Material aluminum die-casting cabinet
    Weight of cabinet 18Kg
    Driving method 1/4scan constant current
    Frame frequency / Hz/S ≥60
    Refresh frequency / Hz/S 600~2000
    Brightness 7000cd/m2
    Operating temperature –25C°~65C°
    Storage temperature –40C°~70C°
    Operation humidity 10%-90%
    Storage humidity 10%-90%
    IP Rrating (Front/Rear) IP65/ IP54
    Working vlotage AC220V / AC110V ±10%
    Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
    Brightness adjustment 256 levels of each color(manually)
    Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control system linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
    Average of non-failure life ≥50,00h
    Life span ≥100,000h
    Functionaless dot rate ≤0.0001
    Control distance

    CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km



    Stage Events Rental LED Display Nova Control System Long Lifespan 640mmx640mm
