|Place of Origin:||Shenzhen, China|
|Certification:||CCC, CE, ROHS|
|Model Number:||PR - P2.97|
|Minimum Order Quantity:||Negotiation|
|Packaging Details:||flight case; export wooden case|
|Delivery Time:||15~25 working days|
|Payment Terms:||T/T, Western Union, MoneyGram|
|Name:||Large Outdoor Screen||Working Voltage:||AC100V - 240V|
|Cabinet Size:||500mm * 500mm||Driving IC:||MBI5153|
Aluminum Large Outdoor Screen Hire 60 Frame Frequency 16 Bits Grey Scale
Rental & Stage --- Indoor:
PASSION LED Slim Rental Series provide an excellent solution to rental client due to its lightweight and slim shape.Fast and simple setup not only saves installation time but also labor cost saving,Its perfect performance on vivid quality absolutely brings an amazing visual feelings to audiences.
Product Features of Large Outdoor Screen:
The screen could be hung up for different kinds of event. And it also could be put on the floor.
2. Cabinet edge protection design:
The bottom modules on the cabinet are about 5mm off the round. So they will not be hit when we put the cabinets on the ground. This feature greatly protects the LEDs during assembly and disassembly.
4. Quick and more secure assembly:
Only 2 steps to lock the cabinets together. And the lock is with Anti-release design which makes it more secure.
Detail Specifications of Large Outdoor Screen:
|Physical Parameter||Pixel Configuration||1R1G1B|
|Pixel Pitch (mm)||2.97|
|Pixel Matrix per m2 (dots)||112896|
|Pixel Matrix per Module||84*84|
|Pixel Matrix per Panel||168*168|
|Module Dimensions (L*W) / (mm)||250*250|
|Module Quality per Cabinet||2*2|
|Panel Dimension (L*W*H) / (mm)||500*500*78|
|Panel Material||Die-Casting Aluminum|
|Panel Weight (Kg)||7|
|Electronic Parameter||Color Grayscale (Bit)||16|
|Gray Scale per Color (Level)||65536|
|Refresh Rate (Hz)||1920|
|Frame Frequency (Hz)||50/60|
|Signal Transmission Distance (m)||CAT5 cable:<100m；Single mode fiber:<10km|
|Optical Parameter||Brightness (cd/m2)||≥1000|
|Color Temperature (K)||6500-7500|
|Optimal Horizontal Viewing Angle (°)||160|
|Optimal Vertical Viewing Angle||160|
|Electrical Parameter||AC Input Voltage (V)||100~240|
|AC Input Frequency (Hz)||50/60|
|AC Input Power Maximum Value (W/m2)||800|
|AC Input Power Typical Value (W/m2)||300|
|Circumstance Parameter||Storage Temperature (℃)||-40~+60|
|Operating Temperature (℃)||-20~+50|
|Storage Humidity (RH)||10%~90%|
|Operating Humidity (RH)||10%~90%|
|IP Rating (Front / Rear)||IP63 / IP54|
|Lifrtime Typical Value (Hrs)||100,000|
|Installation type||Cabinet Installation Type||Rental|
|Maximum Number of Panel for Lifting||12|
1. Your inquiry about our products or the price will be replied within 8 hours.
2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.
4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
This series products are widely applied to stage show, concert, TV station, Brand presentation, stadium display screen and so on.
