Home ProductsCurved LED Display

IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current

IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current

    • IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current
    • IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current
    • IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current
  • IP65 Curved LED Display P10 , Indoor LED Display Board NATIONASTAR Constant Current

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: PASSION
    Certification: CE ,ROSH
    Model Number: P10mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: wooden case
    Delivery Time: 15 days after deposit payment arrival
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 2000SQm/Month
    Contact Now
    Detailed Product Description
    IP Rate: 65 LED Brand: NATIONASTAR
    Working Voltage: AC100-240V Cabinet Size: 960mm * 960mm
    Brightness: 5000CD/sqm Refresh Rate: 1920Hz

    Outdoor Advertising Curved LED Display, P10mm Fixed Curved LED Sign With 960mm Cabinet


    Product Description:


    Curved LED displaly P10mm model is a by constant current driver IC,control of semiconductor light emitting diode display mode,by controlling the trichromatic lamp brightness changes,showing a variety of colors,display text,images,animation,graphics,quotes,video,video signal display screen



    Mainly used for outdoor high density picture display uses,waterproof and dust proof.Product thin,easy to install and use.



    High brightness to meet the needs of outdoor environment.High gray and high refresh,meet the camera,camera equipment to shoot demand,3535 table stick package,to meet the large angle of view.





    Detail Specifications of the Outdoor Advertising curved LED Display P10mm model:



    Parameter Value
    Physical Parameter Pixel Configuration 1R1G1B
    Pixel Pitch (mm) 10
    Pixel Matrix per m2 (dots) 10000
    Pixel Matrix per Module 32*16
    Pixel Matrix per Panel 64*64
    Module Dimensions (L*W) / (mm) 320*160
    Module Quality per Cabinet 3*6
    Panel Dimension (L*W) / (mm) 960*960
    Panel Material Iron / Aluminum
    Panel Weight (Kg) 55
    Electronic Parameter Color Grayscale (Bit) 14
    Gray Scale per Color (Level) 16384
    Refresh Rate (Hz) 1280
    Driving Type 1/2
    Frame Frequency (Hz) 50/60
    Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
    Optical Parameter Brightness (cd/m2) ≥5500
    Color Temperature (K) 6500-7500
    Color Contrast 4000:1
    Optimal Horizontal Viewing Angle (°) 160
    Optimal Vertical Viewing Angle 160
    Electrical Parameter AC Input Voltage (V) 100~240
    AC Input Frequency (Hz) 50/60
    AC Input Power Maximum Value (W/m2) 1300
    AC Input Power Typical Value (W/m2) 400
    Circumstance Parameter Storage Temperature (℃) -40~+60
    Operating Temperature (℃) -20~+50
    Storage Humidity (RH) 10%~90%
    Operating Humidity (RH) 10%~90%
    IP Rating (Front / Rear) IP65 / IP63
    Lifrtime Typical Value (Hrs) 100,000
    Installation type Cabinet Installation Type Fixed
    Maximum Number of Panel for Lifting 8




    Product Advantages:



    1. Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;



    2. Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle, at this range, no picture change, no color excursion;



    3. To pictures and character, have clear, exquisite and real display effect;



    4. High intensity and can be adjusted, so can meet the request of the customers according to the

    application environment;



    5. Can repair each led lamps, so the cost of maintain is lower, and easy to repair





    Trade Articles:



    1). Trade terms: FOB,CIF,EXW

    2). Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

    3)  Payment condition: T/T ,30% deposit before production, 70% balance before delivery

    4). Production lead time less 20 sqm: 8-15days, more than 50 sqm:20days. Sample can be deliveried within 3days
    5). Shipping: by sea,by air and by express delivery
    6). Shipping port: Shenzhen, Mainland China




    Application Area:


    public place:bus,subway, train station, airport, book store, park, exhibtion hall, stadium, museum,buildings, highway, school, meeting room, wedding;

    Budiness orginazations: supermarket, shopping mall, hotels, restaurant,hospital;

    Financial Orginazations: bank, insurance company, stock company, pawnshop;

    Entertainment: theater, clubs, bars,KTV, internet bars;
