Name: High Contrast LED Stage Backdrop Low Power Consumption 20 Watt 6mm Pixels
Brand: PASSION LED DISPLAY
SKU: STAGE LED DISPLAY

Home Products Stage LED Display

High Contrast LED Stage Backdrop Low Power Consumption 20 Watt 6mm Pixels

Product Details:

Place of Origin:	CHINA
Brand Name:	PASSION LED DISPLAY
Certification:	CE ROHS
Model Number:	STAGE LED DISPLAY

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	Negotiation
Packaging Details:	Flight case and wooden case
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	5000 Square meter per month

Contact Now

Detailed Product Description

Usage:	Indoor Fixed	Tube Chip Color:	Full Color
Pixels:	6mm	Brightness:	6000CD/sqm
Weight Cabinet:	36KG	Resolution Of Cabinet:	128*128
High Light:	stadium led display , stage background led screen

High Contrast LED Stage Backdrop Low Power Consumption 20 Watt 6mm Pixels

LED Stage Backdrop selling point:

High contrast ratio. High refresh rate (3000HZ), high gray level (14bit), can support 16 data processing, the picture clear fluid.

Scientific cabinet design, good compatibility.
While designing, we uphold the concept of energy efficiency and environmental protection.Using the standardized cabinet, the cabinet can be convenient for Installation and maintenance in different environment, meanwhile the light, thin cabinet reduces The shipping cost.

SPECIFICATION of LED Stage Backdrop:

LED Module	Pitch/mm	PH6
	Module size/mm	192*192
	Density of pixel/(dots/m2)	27777
	Pixel composition	1R1G1B
	Led encapsulation	3535 SMD 3 in 1
	Resolution of module	32*32
LED Screen	Optimum viewing distance	5~50M
	View angle	H:±160°;V±120°
	Average power consumption	400W/sqm
	Max power consumption	1200W/sqm
	Module quantity	4*4pcs
	Size of cabinet/mm	768*768
	Resolution of cabinet	128*128
	Cabinet Material	Iron Cabinet (Aluminum Cabinet optional)
	Weight of cabinet	36Kg
	Driving method	1/8scan constant current
	Frame frequency / Hz/S	≥60
	Refresh frequency / Hz/S	600~2000
	Brightness	6000cd/m2
	Operating temperature	–25C°～65C°
	Storage temperature	–40C°～70C°
	Operation humidity	10%-90%
	Storage humidity	10%-90%
	IP Rrating (Front/Rear)	IP65/ IP54
	Working vlotage	AC220V / AC110V ±10%
	Grey scale/color depth	displaying colors≥16.7M(synchronized); 14bits
	Brightness adjustment	256 levels of each color(manually)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
	Average of non-failure life	≥50,00h
	Life span	≥100,000h
	Functionaless dot rate	≤0.0001
	Control distance	CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

LED Stage Backdrop Factory Introduction:

PASSION LED was founded in the year 2004, a professional led display manufacturer with dedicated R&D, quality control production, marketing and Project Engineering service. All of our led display, led screen, led video wall, led display panel,led display screen,led curtain display, led dance floor, led floor, flexible led display can be redesigned to suit your exact requirements,we will be happy to discuss your sign needs, and develop a completely bespoke display solution. All our products are wlecomed to your inquiry.
