Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle

Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle

  • Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle
  • Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle
  • Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle
  • Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle
Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle
Product Details:
Place of Origin: SHENZHEN , CHINA
Brand Name: PASSION
Certification: CE ROHS
Model Number: P3.91mm, P4.8mm, P5.6mm, P6.2mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotioation
Price: Negotiation
Packaging Details: Flight Case & Wooden Case
Delivery Time: 15 ~ 20 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 square meter per month
Contact Now
Detailed Product Description
Cabinet Size:: 500mm * 500mm, 500mm * 1000mm Also Called: Stage Video Screen
Display Function: Video Application: Stage
Refresh Rate: 3840Hz IP Rate: 43
Brightness: 1200CD/SQM Material: Aluminum Die-casting
High Light:

stadium led display

,

led backdrop screen

Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle





ABOUT PASSION Stage Video Screen



Who we are?

We are a full color LED screen manufacturing specialist in Shenzhen,China.With years' development,we have worked out many states of the art products for our clients.We're please to help our customers to realize their goals through our LED screen.



What we have?

Over 5000 sq.m2 factory area,hundreds of employees,many high-tech machines to composite production lines,experienced R&D team,etc.



What we offer?

Our products cover infoor,outdoor,curtain and curved LED screens.They can be applied in different situations serving for different purposed accordingly.Besides,we are capable of providing customized solution for clients based on their special requirements.





Specification of Stage Video Screen :



Item Indoor
Fantasy Series 3.91mm 4.81mm 5.6mm 6.2mm
LED Configuration 1R1G1B SMD2020 Black 1R1G1B SMD2020 1R1G1B SMD3528 1R1G1B SMD3528
Module Size 250mm*250mm 250mm*250mm 250mm*250mm 250mm*250mm
Module resolution 64*64dots 52*52dots 44*44dots 40*40dots
Pixel Density 65536picels/m2 43264picels/m2 30976picels/m2 25600picels/m2
Brightness ≧1200cd/m2 ≧1200cd/m2 ≧1200cd/m2 ≧1500cd/m2
Panel Resolution 128*128dots 104*104dots 88*88dots 80*80dots
Power Consumption

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Avg:105w/panel

Max:300w/panel

Driving Mode 1/16 1/13 1/11 1/10
Material Aluminum Die-casting
Refresh Rate 2880HZ
Gray Scale 65536level
Viewing Angle(H/V) 140°/140°
Panel Size/Weight 500*500*75mm/6.5kg
IP Rating IP3X
Operating Temperature -20℃-60℃
Operating Humidity 10%-90%RH
Lifespan 10000hrs at 50% brightness
Control System Novastar/Linsn





Supply Ability of Stage Video Screen :



5000 Square Meter/Square Meters per Month





FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q8: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.







Product features :



1. High quality LED chip and high anti-static electricity capacity.



2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.





Fast Locks Stage Video Screen High Pixel Density IP3X Wide Viewing Angle 0
