Name: Wide View Angle RGB Outdoor LED Signs Display Board 1R1G1B 1920Hz Refresh Rate
Brand: PASSION
SKU: P10mm

Home Products Outdoor LED Signs

Wide View Angle RGB Outdoor LED Signs Display Board 1R1G1B 1920Hz Refresh Rate

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	PASSION
Certification:	CE , ROSH
Model Number:	P10mm

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Wooden case or Flight case
Delivery Time:	15 days after deposit payment arrival
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	2000SQm/Month

Contact Now

Detailed Product Description

Usage:	Outdoor	Cabinet Size:	960mm * 960mm
Working Voltage:	AC100-240V	Display Function:	Video
Brightness:	6000CD/sqm	Refresh Rate:	1920Hz
High Light:	full color programmable led signs , outdoor programmable led signs

RGB outdoor led programmable sign display board, full color 960*960mm led message sign

Description:

1. Advanced SMT encapsulation technology ensure the led lamps in good uniformity,and wide view angle,lower power consumption,energy-saving more than 30%

2. Good waterproof, IP65 grade, Anti-corrosion,Antifogging,suit for outdoor different weather condition,keep long life time.

3. High pixel density,High brightness and Long view distance,can be seen from far away 100 meters

4.Good protection with soft mask and thick bongrace,avoid to be broken and to hurt sportsmen

5. Brightness can be adjusted automatically according to different surrondings,
can be set to open and close the screen on fixed automatically

6. Widely used for commercial advertising, match live broadcasting,sport rebroadcast, company logo, for fixed or for rental use,panel size can be customized according different requirements.

Product Spefications:

LED Module	Pitch/mm	PH10
	Module size/mm	320*160
	Density of pixel/(dots/m2)	10000
	Pixel composition	1R1G1B
	Led encapsulation	SMD3535
	Resolution of module	32*16
LED Screen	Optimum viewing distance	8~100M
	View angle	H:±120°;V±60°
	Average power consumption	300W/sqm
	Max power consumption	800W/sqm
	Module quantity	3 * 6pcs
	Size of cabinet/mm	960*960
	Resolution of cabinet	96*96
	Cabinet Material	Iron Cabinet (Aluminum Cabinet optional)
	Weight of cabinet	55Kg
	Driving method	1/2scan constant current
	Frame frequency / Hz/S	≥60
	Refresh frequency / Hz/S	2000
	Brightness	6500cd/m2
	Operating temperature	–25C°～65C°
	Storage temperature	–40C°～70C°
	Operation humidity	10%-90%
	Storage humidity	10%-90%
	IP Rrating (Front/Rear)	IP65/ IP54
	Working vlotage	AC220V / AC110V ±10%
	Grey scale/color depth	displaying colors≥16.7M(synchronized); 14bits
	Brightness adjustment	256 levels of each color(manually)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
	Average of non-failure life	≥50,00h
	Life span	≥100,000h
	Functionaless dot rate	≤0.0001
	Control distance	CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

All our module chip are from Taiwan Epistar. We guarantee our high quality from the first step !

All our modules are strictly tested one by one !

We have special workers to make sure every module works well !

Our Services

1. Your inquiry related to our products or price will be replied in 8hrs.
2. OEM & ODM,any your customized lightings we can help you to design and put into product.
3. Distributoership are offered for your unique design and some our current models.
4. Protection of your sales area,ideas of design and all your private information.
5. Best cost performance and perfect service before and after sales.
