RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan

RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan

  • RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan
  • RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan
  • RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan
  • RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan
RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION LED
Certification: CE, ROSH
Model Number: P10 - F
Payment & Shipping Terms:
Minimum Order Quantity: 5 SQM
Price: Negotiation
Packaging Details: fight case or wooden case
Delivery Time: 15 working days
Payment Terms: Western Union, MoneyGram, T/T, , L/C
Supply Ability: 2000 square meter per month
Contact Now
Detailed Product Description
Pixel Pitch: P10mm Weight: 50Kg/Sqm
Module Size: 320mm * 160mm Module Resolution: 32 * 16 Dots
Brightness: 6000-8000cd/dqms Grey Level: 13-15bit
Viewing Angle: 120/140 Material: Iron Or Aluminum
High Light:

front maintenace led display

,

p10 outdoor led display

RF Front Service LED Display , LED Wall System 13-15 Bit Grey Level Long Lifespan



Features of this outdoor advertising digital display screens



LED Display Outdoor, also called led screen, led video wall, or led sign, with its unique advantages,has gradually replaced the traditional billboards, light boxes,etc. LED display outdoor has become a new force in the media industry.



LED display outdoor are the ultimate solution for businesses that want to use cost effective and advanced technology to reach outdoor public and make a brilliant impact with ultra-bright visuals, full alpha-numeric text, and graphics.



LED Display Outdoor Features:



1. Easy to Install: No need to do structure, can directly mounted the LED display on the wall with screws.

2. Easy to maintenance: The LED cabinets can be open from the front, maintenance person is easy to open and maintenance the LED Display from the front.

3. SMD 3-in-1 LEDs: Ensure seamless and flatness,wide viewing angle,nice video effect.

4. Support all formats of videos,graphics,images,texts,messages,flash,animation,etc.

5. High brightness can the brightness can be adjustable according to the surrounding environments.

6. Support PC online or offline control, also can remote control with asynchronous system,wifi control, 3G control.




1) High brightness for outdoor advertising;

2) Smooth image, DIP(One LED in One Pixel), reduced the amount of LEDs, improved the image effective

3) More wide viewing angle.

4) Low cost, high return. Cheap price than other outdoor advertising digital display screenss.



Promotion: outdoor advertising digital display screens with high quality is the most popular for outdoor advertising. It canbe used for outdoor fixed and rental market. You can see this kind of led screen in the shopping mall, airport, train stations, walking street, square, park, Stadium, Plaza, Expo Center, Business Center, CBD, Governmenr Project, High buildings, ect.



Product Specifications:



LED Module Pitch/mm PH10
Module size/mm 160*160
Density of pixel/(dots/m2) 10000
Pixel composition 1R1G1B
Led encapsulation DIP346
Resolution of module 16*16
LED Screen Optimum viewing distance 8~100M
View angle H:±120°;V±60°
Average power consumption 300W/sqm
Max power consumption 1000W/sqm
Module quantity 6 * 6pcs
Size of cabinet/mm 960*960
Resolution of cabinet 96*96
Cabinet Material Iron Cabinet (Aluminum Cabinet optional)
Weight of cabinet 55Kg
Driving method 1/4scan constant current
Frame frequency / Hz/S ≥60
Refresh frequency / Hz/S 600~2000
Brightness 7000cd/m2
Operating temperature –25C°~65C°
Storage temperature –40C°~70C°
Operation humidity 10%-90%
Storage humidity 10%-90%
IP Rrating (Front/Rear) IP65/ IP54
Working vlotage AC220V / AC110V ±10%
Grey scale/color depth displaying colors≥16.7M(synchronized); 14bits
Brightness adjustment 256 levels of each color(manually)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
Average of non-failure life ≥50,00h
Life span ≥100,000h
Functionaless dot rate ≤0.0001
Control distance CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km
