RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard

RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard

  • RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard
  • RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard
  • RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard
  • RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard
RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC, CE, ROHS
Model Number: P10mm
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Flight case, export wooden case
Delivery Time: 10-20 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000sqm/month
Contact Now
Detailed Product Description
Usage: Indoor Meterial: Aluminum
Cabinet Size: 960mm * 960mm Refresh Rate: 3840
Module Size: 320mm * 320mm Working Voltage: AC 100 ~ 240V
Brightness: 1500CD/sqm IP Rate: 43
High Light:

indoor advertising boards

,

indoor advertising display

RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard





Features of Indoor Advertising Boards :



P10 Indoor fixed led display with good dustproof function.



Four cooling holes on the back side of the cabinet ensure the heat dissipation.



It has a 8~10 meter viewing distance .



P10 led display is widely used at large indoor theater, Stadium Hall, Meeting Hall.



It is the most economic indoor display solution.





Advantages of Indoor Advertising Boards :



In the material selection of indoor P10 led display, we keep strictly control on the cabinet structure quality which will directly influence the screen flatness.



During the aging testing, calibration is an important procedure which help improve the color uniformity and brightness of P10 led display.





FAQ about of Indoor Advertising Boards  :



1. How to realize the control automation of led displays ?



By brightness automatic adjustment sensor , temperature automatic adjustment sensor, and the power up and off automatic adjustment software ...





2. How to realize the management of various videos or programmes sources ?



Usually we need a led display processor to handle all the program sources from different channel...





Description and Specification of of Indoor Advertising Boards  :



Indoor Advertising Boards
Model PI-P6 PI-P8 PI-P10
Pixel Pitch 6 mm 8 mm 10 mm
LED Type SMD3528 SMD3528 SMD3528
Configuration 1R1G1B 1R1G1B 1R1G1B
Module Size 192*96 mm 256*128 mm 320*160 mm
Pixel Density 27777 pixel/㎡ 15625 pixel/㎡ 10000 pixel/㎡
Refresh Rate ≥ 1500Hz ≥ 1920Hz ≥ 1920Hz
Gray Scale 16 Bit 16 Bit 16 Bit
Brightness ≥ 1800 cd/㎡ ≥ 1200 cd/㎡ ≥ 1200 cd/㎡
Scan Way 1/8 1/8 1/4 (1/8 is Optional)
Frame Rate 50HZ~60HZ 50HZ~60HZ 50HZ~60HZ
Viewing Angle H:140°, V:140° H:140°, V:140° H:140°, V:140°
Cabinet Resolution 160*128 Dots 128*96 Dots 128*96 Dots
Material Aluminum OR Iron Aluminum OR Iron Aluminum OR Iron
Cabinet Size 960*768*110mm 960*960*110mm 960*960*110mm
Cabinet Weight 24Kg 30Kg 30Kg
IP Rating IP31 IP31 IP31
Max.Power Consumption 450W/Panel 370W/Panel 320W/Panel
Avg.Power Consumption 150W/Panel 120W/Panel 105W/Panel
Control System Nova/Linsn/Dbstar Nova/Linsn/Dbstar Nova/Linsn/Dbstar
Operation System Windows/me/200NT/XP Windows/me/200NT/XP Windows/me/200NT/XP
Working-Temperature -20℃~60℃ -20℃~60℃ -20℃~60℃
Working Humidity 10%~90% RH 10%~90% RH 10%~90% RH
Input Voltage AC 110~220 V (±5%) AC 110~220 V (±5%) AC 110~220 V (±5%)
Blind spot rate ≤0.01% ≤0.01% ≤0.01%
MTBF 35000 Hour 35000 Hour 35000 Hour
Lifespan 100000 Hour 100000 Hour 100000 Hour
Certification CCC,CE,RosH,ETL CCC,CE,RosH,ETL CCC,CE,RosH,ETL





RGB P5 Indoor Advertising Boards , Full Color LED Display Screen Fixed Billboard 0
