Name: Seamless Stage LED Video Wall Full Color With Aluminum Slim Rental Cabinet
Brand: PASSION
SKU: P2.6mm, P2.97mm, P3.91mm, P4.81mm

Home Products Indoor LED Video Wall

Seamless Stage LED Video Wall Full Color With Aluminum Slim Rental Cabinet

Product Details:

Place of Origin:	SHENZHEN , CHINA
Brand Name:	PASSION
Certification:	CE ROHS
Model Number:	P2.6mm, P2.97mm, P3.91mm, P4.81mm

Payment & Shipping Terms:

Minimum Order Quantity:	Negotioation
Price:	Negotiation
Packaging Details:	Flight Case & Wooden Case
Delivery Time:	15 ~ 20 working days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	5000 square meter per month

Contact Now

Detailed Product Description

Panel Weight:	13Kg	Material:	Die Casting Aluminum
Referesh Rate:	3840Hz	Usage:	Indoor
Pixels:	3.91mm	Display Function:	Video
Module Size:	250mm*250mm	Warranty:	2 Years
High Light:	led screen video wall , rgb led video wall

Stage Seamless LED Video Wall, Full Color With Aluminum Slim Rental Cabinet

Product features of RGB Stage LED Display:

1. High quality LED chip and high anti-static electricity capacity.

2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle.

Supply Ability of RGB Stage LED Display :

5000 Square Meter/Square Meters per Month

Specification of RGB Stage LED Display:

Indoor slim rental P3.91mm LED screen (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 1000mm)
LED Module	Pitch/mm	PH3.91
	Module size/mm	250*250
	Density of pixel/(dots/m2)	65536
	Pixel composition	1R1G1B
	Led encapsulation	SMD2121 3 IN 1
	Resolution of module	64*64
LED Screen	Optimum viewing distance	3~38M
	View angle	H:±160°;V±120°
	Average power consumption	300W/sqm
	Max power consumption	800W/sqm
	Module quantity	2* 4pcs
	Size of cabinet/mm	500*1000
	Resolution of cabinet	128*256
	Cabinet Material	die-casting aluminum cabinet
	Weight of cabinet	13Kg
	Driving method	1/16 scan constant current
	Frame frequency / Hz/S	≥60
	Refresh frequency/ Hz/S	1920
	Brightness	1000cd/m2
	Operating temperature	–20C°～60C°
	Storage temperature	–40C°～70C°
	Operation humidity	10%-90%
	Storage humidity	10%-90%
	IP Rrating (Front/Rear)	IP43
	Working vlotage	AC110V ±10%
	Grey scale/color depth	displaying colors≥16.7M(synchronized); 14bits
	Brightness adjustment	256 levels of each color(manually)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	Novastar
	Average of non-failure life	≥50,00h
	Life span	≥100,000h
	Functionaless dot rate	≤0.0001
	Control distance	CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

FAQ :

Q1. What is refresh rate?

A: The refresh rate is the number of times a display's image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. For instance, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.

Q2. What is viewing angle?

A: The Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

Q3. What are Pixel Pitch and Pixel Density?

A: The Pixel Pitch is the distance between neighboring pixels. The Pixel Density is the quantity of pixels per square meter.

Q8: What is LED display?

A: The LED display is a new kind of information and communication media, which is composed of the array of LED devices, used to display text, images, videos, TV programs, live broadcast, etc.
