|Place of Origin:||China|
|Brand Name:||PASSION LED|
|Minimum Order Quantity:||Negotiation|
|Packaging Details:||flght case and wooden case|
|Delivery Time:||20~25 working days|
|Payment Terms:||Western Union, MoneyGram, T/T, L/C|
|Supply Ability:||5000 Square meter + per month|
|Led Chip:||Epistar||Tube Chip Cplor:||Full Color|
led perimeter advertising boards,
stadium perimeter led display
AC 220V Perimeter Safety Screens , Pitch Side Advertising Boards 5800cd/㎡
1. Quick installation & maintenance
2. Stronger & more accurate cabinet frame
3. High definition & resolution
4. Better consistency
5. High waterproor performance
6. Soft mask and cover to protect the screen and avoid scratching
7.Metal power box for better heat dissipation
8. High cost-effective
Detail Specifications of the Perimeter LED Display:
|Density of pixel/(dots/m2)||15625|
|Led encapsulation||3535 SMD 3 in 1|
|Resolution of module||32 * 16/40*40|
|LED Screen||Optimum viewing distance||8~75M|
|Average power consumption||400W/sqm|
|Max power consumption||1200W/sqm|
|Module quantity||3 * 6pcs/|
|Size of cabinet/mm||768*768 / 960*960|
|Resolution of cabinet||96*96 / 120 * 120|
|Cabinet Material||Iron Cabinet (Aluminum Cabinet optional)|
|Weight of cabinet||36Kg|
|Driving method||1/4scan constant current|
|Frame frequency / Hz/S||≥60|
|Refresh frequency / Hz/S||600~2000|
|IP Rrating (Front/Rear)||IP65/ IP54|
|Working vlotage||AC220V / AC110V ±10%|
|Grey scale/color depth||displaying colors≥16.7M(synchronized); 14bits|
|Brightness adjustment||256 levels of each color(manually)|
|Input signal||RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc|
|Control system||linsn/Colorlight/Nova(sending card,receiving cards and Hubs)|
|Average of non-failure life||≥50,00h|
|Functionaless dot rate||≤0.0001|
|Control distance||CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km|
Q1. What about the delivery lead time?
A: About 22 days after receiving payment.
Q2. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 4-8 days to arrive. Airline and sea shipping also optional. And you can also designate shipping companies.
Q3. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the solution and places deposits for formal order.
Fourthly We arrange the production.
Q4. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5. Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
