|Place of Origin:||Shenzhen, China|
|Certification:||CCC, CE, ROHS|
|Model Number:||PRO - P3.91|
|Minimum Order Quantity:||Negotiation|
|Packaging Details:||flight case; export wooden case|
|Delivery Time:||15~25 working days|
|Payment Terms:||T/T, Western Union, MoneyGram|
|Other Name:||Event Screen Hire||Grey Scale:||16Bits|
|Module Size:||250mm * 250mm||Working Voltage:||AC100V - 240V|
|Cabinet Size:||500mm * 500mm , 500mm * 1000mm||Life Span:||100000H|
event screen hire,
large outdoor screen hire
4.81mm Pixel Pitch Event Screen Hire , Outdoor Video Screen Rental High Refresh
Features Event Screen Hire :
1. High Definition,wonderful visual performance.
2. High brightness ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3. High resolution could guarantee superior performance even with small screen size.
4.High refresh rate, high grey scale level and high accurate color consistency guarantee the vivid pictures and perfect videos.
5. Super wide viewing angle can be visible in most corners, give you visual enjoyment.
6. SMD technology could guarantee higher flatness and better performance.
7. Aviation plug and quick lock is used, bringing easier cables connection and quicker assembly of cabinets to save time.
8. Low power consumption and fast heat dissipation with dual channel heat dissipation
9. Support a series of detection functions, for example detection of cables failure, detection whether the door of cabinets closed or not, fans` speed monitoring, three-way voltage monitoring and temperature monitoring etc.
Unique color calibration process
Tight bin selection for LED wavelength Deep black levels, contrast ratio 4000:1
Dual signal backup port
UI LCD monitoring display indicates the status
Truss hanging and ground support both available Cable-less between modules
Front and rear access Tools free installation
500mmx500mm or 500mmx1000mm cabinet 80mm thickness, 7 KG per cabinet
Advantages of Event Screen Hire:
Use of Special heat dissipation structure make excellent heat dissipation, Quiet operation without fans.High refresh/High contrast/High grayscale/ Gorgeous picture showing Ultra-wide viewing angle give you the largest screen viewing area.Die-cast aluminum cabinet design light and easy to transport, good flatness and seamless
Special Features of Event Screen Hire:
1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
2. Viewing angle of 140 degrees or more, multi direction viewing display effect is consistent;
3. Integrated blanking circuit, effectively eliminate the ghost line;
4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.
5. Support All Media Format and Display Mode:
DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.
Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet.
Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on .
Detail Specifications of outdoor P3.91mm Slim Rental LED Display:
|Physical Parameter||Pixel Configuration||1R1G1B|
|Pixel Pitch (mm)||3.91|
|Pixel Matrix per m2 (dots)||65536|
|Pixel Matrix per Module||64*64|
|Pixel Matrix per Panel||128*128 / 128*256|
|Module Dimensions (L*W) / (mm)||250*250|
|Module Quality per Cabinet||2*2 / 2*4|
|Panel Dimension (L*W*H) / (mm)||500*500*78 / 500*1000*78|
|Panel Material||Die-Casting Aluminum|
|Panel Weight (Kg)||7|
|Electronic Parameter||Color Grayscale (Bit)||16|
|Gray Scale per Color (Level)||65536|
|Refresh Rate (Hz)||1920|
|Frame Frequency (Hz)||50/60|
|Signal Transmission Distance (m)||CAT5 cable:<100m；Single mode fiber:<10km|
|Optical Parameter||Brightness (cd/m2)||5000|
|Color Temperature (K)||6500-7500|
|Optimal Horizontal Viewing Angle (°)||160|
|Optimal Vertical Viewing Angle||160|
|Electrical Parameter||AC Input Voltage (V)||100~240|
|AC Input Frequency (Hz)||50/60|
|AC Input Power Maximum Value (W/m2)||800|
|AC Input Power Typical Value (W/m2)||300|
|Circumstance Parameter||Storage Temperature (℃)||-40~+60|
|Operating Temperature (℃)||-20~+50|
|Storage Humidity (RH)||10%~90%|
|Operating Humidity (RH)||10%~90%|
|IP Rating (Front / Rear)||IP65 / IP63|
|Lifrtime Typical Value (Hrs)||100,000|
|Installation type||Cabinet Installation Type||Rental|
|Maximum Number of Panel for Lifting||12 / 6|
1. Your inquiry about our products or the price will be replied within 8 hours.
2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.
4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
