1R1G1B 4500nits Outdoor Led Display Board 3.91mm Pixel

1R1G1B 4500nits Outdoor Led Display Board 3.91mm Pixel

1R1G1B 4500nits Outdoor Led Display Board 3.91mm Pixel
1R1G1B 4500nits Outdoor Led Display Board 3.91mm Pixel
1R1G1B 4500nits Outdoor Led Display Board 3.91mm Pixel
Product Details:
Place of Origin: Shenzhen, China
Brand Name: PASSION
Certification: CCC, CE, ROHS
Model Number: PRO - P3.91, P4.81
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: flight case; export wooden case
Delivery Time: 15~25 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000Sqm/month
Contact Now
Detailed Product Description
Pixel Pitch: 3.91mm Grey Scale: 16 Bits
Module Size: 250mm * 250mm Working Voltage: AC100V - 240V
Cabinet Size: 500mm * 500mm Life Span: 100000H
Brightness: 4500CD/sqm Refresh Rate: 3840Hz
High Light:

1R1G1B Outdoor Led Display Board


4500nits Outdoor Led Display Board


3.91mm Pixel Led Video Panel

AC 100V-240V Stage LED Backdrop Screen, High Brightness Smart LED Wall Panel For Rental



Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on.


Advantages of LED Backdrop Screen​:


Use of Special heat dissipation structure make excellent heat dissipation, Quiet operation without fans.High refresh/High contrast/High grayscale/ Gorgeous picture showing Ultra-wide viewing angle give you the largest screen viewing area.Die-cast aluminum cabinet design light and easy to transport, good flatness and seamless



Special Features of LED Backdrop Screen​:


1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
2. Viewing angle of 140 degrees or more, multi direction viewing display effect is consistent;
3. Integrated blanking circuit, effectively eliminate the ghost line;
4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.

5. Support All Media Format and Display Mode:

DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.

Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet



Detail Specifications of LED Backdrop Screen​:


Parameter Value
Physical Parameter Pixel Configuration 1R1G1B
Pixel Pitch (mm) 3.91
Pixel Matrix per m2 (dots) 65536
Pixel Matrix per Module 64*64
Pixel Matrix per Panel 128*128
Module Dimensions (L*W) / (mm) 250*250
Module Quality per Cabinet 2*2 / 2*4
Panel Dimension (L*W*H) / (mm) 500*500*78
Panel Material Die-Casting Aluminum
Panel Weight (Kg) 7
Electronic Parameter Color Grayscale (Bit) 16
Gray Scale per Color (Level) 65536
Refresh Rate (Hz) 1920
Driving Type 1/16
Frame Frequency (Hz) 50/60
Signal Transmission Distance (m) CAT5 cable:<100m;Single mode fiber:<10km
Optical Parameter Brightness (cd/m2) 4500
Color Temperature (K) 6500-7500
Color Contrast 4000:1
Optimal Horizontal Viewing Angle (°) 160
Optimal Vertical Viewing Angle 160
Electrical Parameter AC Input Voltage (V) 100~240
AC Input Frequency (Hz) 50/60
AC Input Power Maximum Value (W/m2) 800
AC Input Power Typical Value (W/m2) 300
Circumstance Parameter Storage Temperature (℃) -40~+60
Operating Temperature (℃) -20~+50
Storage Humidity (RH) 10%~90%
Operating Humidity (RH) 10%~90%
IP Rating (Front / Rear) IP65 / IP63
Lifrtime Typical Value (Hrs) 100,000
Installation type Cabinet Installation Type Rental
Maximum Number of Panel for Lifting 12



Our services:


1. Your inquiry about our products or the price will be replied within 8 hours.

2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.

3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.

4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
